CT LIMIT E

//CT LIMIT E

CT LIMIT E

An efficient and refined electric-assist system on a city bike could be the best feature if used for longer distances or hilly streets. By saving time and money on daily commutes or shopping you also save the planet. Although all CT LIMIT frames are electric-assist ready, we spent time on many aspects of an ideal electric-assisted city bikes and created a trouble-free, efficient, lightweight and high performance city bikes who appreciate class and quality. CT LIMIT E can be ordered with a super lightweight 250W front drive or 350W/500W rear hub drive for those who expect more power and performance. The bike still can be used without electric-assist as a regular bike if you intend to get some exercise too.

Category:

Description

This unique city bike has been a response to those who are looking for exceptional comfort of a recumbent bike but still wish to have a regular bike. Introduced in 2016 after two years of research and development, we finally created a golden bridge between a recumbent and a regular upright bike. CT LIMIT is specifically designed for urban use as an efficient, lightweight and exceptionally comfortable commuting city bike. Its stunning European-inspired style mixed with North American standards is ready for any rear and front carrier rack and shopping basket to fully meet daily commute and shopping. Well-balance geometry, step-through frame equipped with refined components from leading brands; it comes with built-in kickstand and carbon fiber look fenders. It comes in two sizes and four models in attractive and stand-out white colour with a touch of red.

CT LIMIT can arguably be the most comfortable city bike on the market!

CT LIMIT SDTechnical Specifications
Frame:AL7005 T6 heat-treated, disc brake/ V-brake, Electric-assist ready
Saddle:MAXARYA Double-density foam, composite flex base, adjustable
Seat Post:MAXARYA alloy, adjustable
Handlebar:MAXARYA alloy, matte black, 150mm rise, w/riser
Stem:Alloy black, adjustable
Fork:MAXARYA full alloy, 1 1/8” threadless, disc brake/V-brake
Headset:MAXARYA sealed w/45mm alloy cone spacer
Bottom bracket:FPD CH55 body, sealed
Crankset:MAXARYA forged alloy 44/32/24T w/chainguard
Chain:KMC Z99RB silver, rust-proof
Front derailleur:Sram XGen
Rear derailleur:Sram X.9
Cassette:Sram PG970 11-34T
Shifter:Sram X.9 3×9 speed
Brakes:Avid BB7 disc brake
Front wheel:Alexrim EN24 alloy, black, CNC side wall, 36H
Rear wheel:Alexrim EN24 alloy, black, CNC side wall, 8/9/10 speed, 36H
Electric system:250W/36V 350W/36V 500W/48W, rear rack battery pack
Spokes:Stainless steel, silver14G/13G
Tires:MAXXIS Overdrive Elite 1.75”x26” (42-559mm) puncture-proof
Pedals:FPD alloy body w/non-slip insert, w/Cateye reflectors
Overall length:S: 73” (1,855mm) L: 75.2” (1,910mm)
Wheelbase:S: 48.4”, (1,230mm) L: 51” (1,295mm)
Seat height31.5-37.4” (800-950mm)
BB height:11.5” (290mm)
Weight:39-45 Lbs. (17.5-20.5kg)
Weight limit:275 Lbs. (125 kg) Combined rider, bike and cargo
Rider’s height:S: 5”-6’ 1” (152-185cm) L: 5’ 8”-6’ 8” (173-203cm)
Gear inch ratio:18-102” (46-259cm)
Colour:White w/clear coat
MSRP:Standard: $US Large: $US
